7-5
EVENT PROCESSOR ARRAY
7.1.2 EPA Pending Registers
Figures 7-5 and 7-6 illustrate the EPA pending registers, EPA_PEND and EPA_PEND1, for the
8XC196Lx microcontroller family.
EPA_PEND Address:
Reset State:
1FA2H
0000H
When hardware detects a pending EPA6–9 or OVR0–3, 8–9 interrupt request, it sets the
corresponding bit in the EPA interrupt pending register (EPA_PEND or EPA_PEND1). The EPAIPV
register contains a number that identifies the highest priority, active, shared interrupt source. When
EPAIPV is read, the EPA interrupt pending bit associated with the EPAIPV priority value is cleared.
15 8
Lx — — EPA6 EPA7 EPA8 EPA9 OVR0 OVR1
7 0
0VR2 OVR3 — — — — OVR8 OVR9
Bit
Number
Function
15:0 † Any set bit indicates that the corresponding EPA x interrupt source is pending. The bit is
cleared when software reads the EPA interrupt priority vector register (EPAIPV).
† Bits 2–5 and 14–15 are reserved on the 8XC196L x device family. For compatibility with future
devices, write zeros to these bits.
Figure 7-5. EPA Interrupt Pending (EPA_PEND) Register
EPA_PEND1 Address:
Reset State:
1FA6H
00H
When hardware detects a pending EPA x interrupt, it sets the corresponding bit in the EPA interrupt
pending register (EPA_PEND or EPA_PEND1). The EPAIPV register contains a number that
identifies the highest priority, active, multiplexed interrupt source. When EPAIPV is read, the EPA
interrupt pending bit associated with the EPAIPV priority value is cleared.
7 0
— — — — COMP0 † COMP1 † OVRTM1 OVRTM2
Bit
Number
Function
7:4 Reserved; always write as zeros.
3:0 † Any set bit indicates that the corresponding EPA x interrupt source is pending. The bit is
cleared when the EPA interrupt priority vector register (EPAIPV) is read.
† 87C196LA, LB only; reserved on 83C196LD.
Figure 7-6. EPA Interrupt Pending 1 (EPA_PEND1) Register
