J1850 COMMUNICATIONS CONTROLLER
Figure 8-10. IFR Type 2 Message Frame
8.4.2.3 IFR Messaging Type 3: Multiple Bytes, Single Responder
IFR messaging type 3 (Figure 8-11) is ideal for requesting large amounts of information from a
single source in your system. You can compile up to 12 bytes of data from a remote node on a
single request. In our example, for the same amount of CPU overhead as IFR type 1 messaging
exhausted (4.96 ms), you can gather up to twelve times as much information.
Figure 8-11. IFR Type 3 Message Frame
8.5 TRANSMITTING AND RECEIVING MESSAGES
The J1850 controller can transmit and receive messages in either standard or IFR form.
8.5.1 Transmitting Messages
To transmit a standard message, prepare the message in register RAM and then write it to the
J1850 transmit (J_TX) register (Figure 8-12) one byte at a time.
