8XC196L X SUPPLEMENT
3-8
Upper Register File (CA, JR, JT, JV, KR, KT, LA, LB, LD)
0160H 4BH
25H
12H
0140H 4AH
0120H 49H
24H 0100H 48H
Table 3-4. Windows (Continued)
Base
Address
WSR Value
for 32-byte Window
(00E0–00FFH)
WSR Value
for 64-byte Window
(00C0–00FFH)
WSR Value for
128-byte
Window
(0080–00FFH)
NOTE: Locations 1FE0–1FFFH contain memory-mapped SFRs that cannot be accessed through a
window. Reading these locations through a window returns FFH; writing these locations
through a window has no effect.
