7-1
CHAPTER 7
EVENT PROCESSOR ARRAY
The EPA on the 8XC196Lx is functionally identical to that of the 8XC196Jx; however, the
8XC196Lx has only two capture/compare channels without pins instead of four. In addition, the
83C196LD has no compare-only channels.
7.1
EPA FUNCTIONAL OVERVIEW
Table 7-1 lists the capture/compare (with and without pins) and compare-only channels for each
device in the 8XC196Lx and 8XC196Kx families.
The 8XC196Lx’s EPA performs input and output functions associated with two timer/counters,
timer 1 and timer 2, as depicted in Figures 7-1 and 7-2.
Table 7-1. EPA Channels
Device
Capture/Compare
Channels With Pins
Capture/Compare
Channels Without Pins
Compare-only
Channels
8XC196LA, LB
EPA3:0 and EPA9:8
EPA7:6
COMP1:0
8XC196LD
EPA3:0 and EPA9:8
EPA7:6
—
87C196CA, 8XC196J
x
EPA3:0 and EPA9:8
EPA7:4
COMP1:0
8XC196K
x
EPA9:0
—
COMP1:0
