66 Chapter 5: Matrox 4Sight-M hardware reference
PC/104-Plus interface
The Matrox 4Sight-M motherboard has connectors that provide a PC/104-Plus
interface. PC/104-Plus is a standard stackable form factor for PCI busses. The
interface allows you to connect:
• Several Matrox frame grabbers for PC/104-Plus.
• Other third-party PC/104-Plus boards (PCI support).
The Matrox 4Sight-M chassis provides room for up to three PC/104-Plus boards
in total.
Warning
Note that Matrox 4Sight-M cannot tolerate all PC/104-Plus connections; it
supports only PC/104-Plus boards with 3.3V signalling.
Power supply, fan, and chassis
If you have purchased the integrated-unit version of Matrox 4Sight-M, you will
receive a motherboard, equipped with a power-supply and fan, which is encased
in a metal chassis.
If you have purchased the motherboard-only version of Matrox 4Sight-M will
have to supply these components yourself. Refer to Chapter 4: Installing the Matrox
4Sight-M motherboard in a custom chassis for details on the specifications of these
components.
