132 Appendix B: Technical reference
Use the Camera Link cable from your camera manufacturer or from 3M
Interconnect Solutions for Factory Automation, to interface with the above
connectors. Note that this cable is not available from Matrox
Caution
If using the two Camera Link connectors, the cables you choose should be of the
same type and length.
Pinouts of internal connectors and
dip switches
Inside the unit are the following connectors:
• One ATA 44-pin internal connector.
• One ATA 40-pin internal connector.
• The internal connector of the parallel interface.
• One power connector to connect IDE devices.
• One internal dip switch.
6
DATA, INPUT, Z0+
19
DATA, INPUT, Z0-
7
TERMINATED
20
100
Ω
8
DATA, INPUT, Y3+
21
DATA, INPUT, Y3-
9
CLOCK, INPUT , Y+
22
CLOCK, INPUT , Y-
10
DATA, INPUT, Y2+
23
DATA, INPUT, Y2-
11
DATA, INPUT, Y1+
24
DATA, INPUT, Y1-
12
DATA, INPUT, Y0+
25
DATA, INPUT, Y0-
13
INNER SHIELD
26
INNER SHIELD
Manufacturer:
3M Interconnect Solutions for Factory Automation
Camera Link cable Part Number:
14X26-SZLB-XXX-0LC
Medium Configuration
Pin
Signal
Pin
Signal
