110 Appendix B: Technical reference
Motherboard
• EBX form factor (8” x 5¾” or 20.32cm x 14.61cm).
• Integrates processing, display, storage, networking, and I/O functionality.
• Processor:
- 1.3 GHz Intel Celeron M.
- 1.6 GHz Intel Pentium M.
• Chipset:
- GMCH (north bridge) controller - Intel 855GME.
- I/O hub (south bridge) controller - Intel ICH4.
• 1 Mbyte flash BIOS.
• A standard 10/100BaseT Ethernet interface and a Gigabit Ethernet networking
interface
• Two serial, one parallel, four external USB with two internal requiring special
adapters , one audio, and one auxiliary I/O interface.
• A PC/104-Plus interface.
• A four-pin power connector to connect IDE devices. The voltages that can be
drawn are outlined in the following table:
1 2 3 4
