126 Appendix B: Technical reference
9
OPTOTRIG-
I
Opto-isolated trigger negative input.
10
NC
Not connected.
11
LVDSTRIG+
I
LVDS trigger positive input.
12
NC
Not connected.
13
LVDSTRIG-
I
LVDS trigger negative input.
14
GND
Ground.
15
EXTUSERIN1
I
TTL external user input 1.
16
DC_OUT
+12 V power supply. The DC_OUT signal is
protected with a 0.75 A auto-resettable fuse.
17-18
GND
Ground.
19
VSOUT_1-
O
Vertical synchronization 1 negative output.
20
VSOUT_1+
O
Vertical synchronization 1 positive output.
21-22
NC
Not connected.
23
HSOUT_1-
O
Horizontal synchronization 1 negative output.
24
HSOUT_1+
O
Horizontal synchronization 1 positive output.
25-31
GND
Ground.
32
CKOUT_1+
O
Clock output 1 positive.
33
CKOUT_1-
O
Clock output 1 negative.
34
USIN0+
I
Positive user input 0.
35
USIN0-
I
Negative user input 0.
36-37
NC
Not connected.
38
VSOUT_0+
O
Vertical synchronization 0 positive output.
39
VSOUT_0-
O
Vertical synchronization 0 negative output.
40
HSOUT_0+
O
Horizontal synchronization 0 positive output.
41
HSOUT_0-
O
Horizontal synchronization 0 negative output.
42
GND
Ground.
43
CKOUT_0-
O
Clock output 0 negative.
44
CKOUT_0+
O
Clock output 0 positive.
Matrox Meteor-II /Camera Link
Pin
Signal
I/O
Description
