14 2. TV Setup
Setup Procedure
Connect your devices to the TV, making note 1.
of which TV input is used for each device. See
chapter 3, “TV Connections.” The TV and the
devices can be either on or off when connecting.
First select a
device type.
Next perform
IR “learning” (if
available).
Sample Auto Input Sensing screen
Power on the TV if not already on. When the TV 2.
detects a connection, the Auto Input Sensing screen
opens.
t .PTU%FWJDF5ZQFT Specify the device type.
a. In
the Auto Input Sensing screen, press
to move through the device list to select the
device type connected to the input. The device
type you select here will appear as an icon in the
Input Selection menu.
b. 736 and 835 Series Models: To perform
NetCommand “learning” after selecting the
device type, highlight the Learn icon and press
ENTER. See chapter “Initial NetCommand Setup
for Most Devices,” page 53.
t A/V Receiver: The TV can detect audio connections
on the DIGITAL AUDIO OUTPUT jack and the right
(red) analog AVR AUDIO OUTPUT jack.
736 and 835 Series Models: To perform NetCom-
mand “learning” now, highlight the Learn icon in
the Auto Output Sensing screen and press ENTER.
See “Setting Up NetCommand Control of an A/V
Receiver,” page 57.
t HDMI Devices Compatible with the TV’s
NetCommand for HDMI Feature (all models):
Compatible HDMI devices with CEC enabled are
often recognized automatically by the TV. After con-
necting the device, you may briefly see the standard
Auto Input Sensing screen shown above before
the TV recognizes the device type. The TV’s remote
control may operate some device functions without
further setup. To add control over more functions:
All Models: - Program the TV’s remote
control to operate the device.
Setting Up TV Inputs, continued 7 - 36 and 835 Series Models: Perform
NetCommand IR “learning” to add functions.
Press 3. EXIT to close the Auto Input Sensing screen. The
TV will then display the Auto Input Sensing screen for
the next connection it finds.
More About Auto Input Sensing
t $IPPTFBEJGGFSFOUOBNFGPSFBDIJOQVU
t "OUFOOBJOQVUT ANT 1/ANT 2) are never detected,
although you can turn off unused antenna inputs in the
Inputs > Name menu.
t :PVDBODIBOHFUIFEFWJDFUZQFBUBMBUFSUJNFVTJOHUIF
Inputs > Name menu (page 47). Any “learned” NetCom-
mand IR codes will be erased, however.
Changing Devices on an HDMI Input:
Disconnect the HDMI device. 1.
Turn off the HDMI input in the 2. Inputs > Name menu.
Connect the new device and the 3. Auto Input
Sensing screen will display. If you want the device
under NetCommand IR control, perform NetCom-
mand “learning” for the new device.
Note for Analog A/V Receivers
When you disconnect an analog A/V receiver, be
sure to manually change the Speakers setting to
TV to hear sound from the TV speakers.
Controlling A/V Receiver Sound Volume
Although the TV detects when you connect an A/V receiver,
you must use one of the methods below to control sound
volume from the A/V receiver.
With a Standard TV Setup (all models)
t Recommended Method: Program the TV’s remote
control for your A/V receiver and enable the Audio Lock
feature. See Appendix C, page 65.
t 1SPHSBNUIF57TSFNPUFDPOUSPMGPSZPVS"7SFDFJWFS
and set the TV remote’s slide switch to the AUDIO posi-
tion to control A/V receiver volume. Set the switch back
to the TV position to control the TV.
t 6TFUIFSFNPUFDPOUSPMUIBUDBNFXJUIUIF"7SFDFJWFS
With an HDMI CEC-enabled A/V Receiver (all models)
The TV’s remote control may control some or all functions
of the A/V receiver without further setup. Connect the A/V
receiver to the TV with an HDMI cable and test the TV’s
remote control with the slide switch in the TV position.
With NetCommand Control of an A/V Receiver (736 and
835 series models)
t 4FUVQ/FU$PNNBOEDPOUSPMPGUIF"7SFDFJWFSTWPMVNF
functions in the Inputs > AVR menu. The TV’s remote
will then automatically control A/V receiver volume. See
page 57.
t 6TFBOZPGUIFNFUIPETEFTDSJCFEGPSUIFTUBOEBSE
TV setup.
