Page 34
34
4. TV Operation and Features
This section provides Instructions for viewing 3D video
using the TV’s 3D feature. The 3D options are found in
the Setup > 3D menu described on page 46 .
Initial Set-Up
Check if your HDMI 3D video source device outputs
1.
a 1080p 60 Hz signal. This information will be
needed when you assign an input name in the Auto
Input Sensing screen.
If your 3D glasses came with an emitter box,
2.
connect the emitter box to the 3D GLASSES
EMITTER jack on the back of the TV. See page 9
for the location of the jack.
Power on the TV and the source device.
3.
Connect the source device to the TV’s HDMI input.
4.
When the
5.
Auto Input Sensing screen displays,
name the input according to the table below.
The signal type and choice of name are important
because the TV will process the video signal
differently depending on the name you assign. If
your source device is a high-definition disc system,
such as Blu-Ray or HD DVD, or is a game console,
the signal must be 1080p at 60 Hz.
Press
6.
EXIT to close the Auto Input Sensing screen.
Source of 3D Video
Type of 3D Video Signal
Name to Assign to
Video Input
Computer
Recommended: 1080p 60 Hz (1920 X 1080). The image will fill
the TV screen.
Other 60-Hz computer video signals compatible with the TV will
display with black bars. See “Computer Display Formats” on
page 17.
PC
Any other 3D video
source
To see 3D video, signal must be 1080p 60 Hz
Any name other than
PC
To Watch 3D Video
Press
1.
INPUT to display the Input Selection menu.
Highlight the icon for the 3D video input and press
2.
ENTER.
Press
3.
MENU and select the Setup > 3D Mode menu.
Set
4.
3D Mode to On. The On setting will be memo-
rized for the current input when you exit this menu.
Press
5.
EXIT to close the menu.
To Watch Regular (non-3D) Video
The 3D Mode setting is memorized for each input.
When you want to watch non-3D video on the input
selected above:
Select the input in the
1.
Input Selection menu.
Open the
2.
Setup > 3D menu and set 3D Mode to
Off.
3D Video
Use the Setup >
3D Mode menu to
enable 3D video
viewing.
