6. NetCommand IR Control (736 and 835 Series TVs) 61
Setup to Control Automatic Video
and Audio Switching via HDMI
Follow these steps if you wish NetCommand to control
switching of A/V receiver video as well as audio inputs.
When this setup is complete, you can use the TV’s
Input Selection menu to select a video device con-
nected to the A/V receiver. You can also perform addi-
tional NetCommand setup to control devices connected
to the A/V receiver.
Display the 1. Inputs > AV Receiver menu.
Note: The labels Input1 through Input5 in the Learn
column are arbitrary names used by the TV to
distinguish between A/V receiver inputs.
With the highlight in the 2. Learn column, highlight
one of the Input labels (Input1 through Input5).
Press 3. ENTER and the highlighted Input label will start
flashing to indicate readiness for “learning.”
While the 4. Input text is flashing, press and hold the
key on the A/V receiver’s remote control for the
input you wish to associate with the selected Input
label.
When a check appears next to the 5. Input label,
release the remote control key.
t *GUIFUFYUTUPQTGMBTIJOHCFGPSFUIFDIFDLNBSL
appears, repeat this step.
t 5PFSBTFUIF*3DPEFKVTUiMFBSOFE
wQSFTTCANCEL
while the name is highlighted.
On the 6. TV’s remote control, press once. The
highlight will move automatically to the associ-
ated Assign Input column (Assign Input1 through
Assign Input5).
Setting Up NetCommand Control of
an A/V Receiver, continued Use 7. to highlight the device type connected to
the A/V receiver input just “learned.” The Assign
Input column contains a list of possible device
types.
In the example above, a DVD player is connected to
the A/V receiver input the TV knows as Input1.
The device type you select here will appear as an
icon in the TV’s Input Selection menu. You can
assign each device type in the list only once.
Press 8. EXIT if finished or repeat these steps for addi-
tional video sources connected to the A/V receiver.
NetCommand IR Control of a Device Connected
to an A/V Receiver with HDMI Output
Use this setup if you wish to have NetCommand control
a device sending audio and video through the A/V
receiver to the TV via HDMI.
Note: If your A/V receiver and the connected device
have CEC capability, you may be able to par-
tially operate the device using the TV’s remote
control without any special setup. In that case,
use this procedure to add commands not avail-
able with CEC.
Set up NetCommand control of A/V receiver audio/ 1.
video switching via HDMI as described on this
page.
TV
Source Device
A/V Receiver
Any type of
audio/video
connection
HDMI
cable from
TV to A/V
receiver
Press 2. EXIT to close any open menus and return to
normal TV viewing.
Press 3. INPUT to open the Input Selection menu.
Highlight the icon for an A/V receiver input 4.
assigned in “Setup to Control Automatic Video and
Audio Switching via HDMI” on this page .
Press 5. ENTER to switch the TV to the A/V receiver and
the A/V receiver to the device.
Open the 6. Inputs > Learn menu.
Perform NetCommand “learning” for the device by 7.
following the steps in “Initial NetCommand Setup
for Most Devices,” page 53.
