68 Maintaining and Troubleshooting the Gateway ALR 7300 Server
• Large Disk Access Mode: options include DOS and Other . Select
DOS if you are using DOS or one of the DOS-based operating
systems. Select Other if you are using another operating system
such as UNIX. A large disk is considered one that has more than
1024 cylinders, 16 heads, or 63 tracks per sector.
• Local Bus IDE Adapter enables or disables the two channels of
the onboard IDE adapter. The options are
Disable , Primary ,
Secondary , and Both .
• Resource Configuration opens the Resource Configuration
screen. Details of this screen are provided in the section, “Resource
configuration screen” on page 69.
• Peripheral Configuration opens the Peripheral Configuration
screen. Details of this screen are provided in the section,
“Peripheral configuration screen” on page 72.
• Keyboard Features opens the Keyboard Configuration screen.
Details of this screen are provided in the section “Keyboard
features screen” on page 74.
• Cache Memory opens the Cache Memory Configuration screen.
Details of this screen are provided in the section “Cache memory
screen” on page 75.
• Advanced Chipset Control opens the advanced chipset control
screen which contains a single field. The field is
ECC Config ,
which allows you to set the extent of error checking and correction
that the system uses. The options for this field are
Disabled, EC,
ECC, and ECC Scrub.
• Embedded PCI SCSI: Channel A enabling this field turns on
channel A of the optional integrated SCSI adapter. Select the Scan
First option if the server will boot from a hard disk or select the
Scan Last option if the server will boot from a CD-ROM. The
options are
Enabled and Disabled .
• Embedded PCI SCSI: Channel B enabling this field turns on
channel B of the optional integrated SCSI adapter. Select the Scan
First option if the server will boot from a hard disk or select the
Scan Last option if the server will boot from a CD-ROM. The
options are
Enabled and Disabled .
