114 Maintaining and Troubleshooting the Gateway ALR 7300 Server
DIMM configurations
Refer to the following table to configure the system random access memory
(RAM).
Total DIMM Socket 1 DIMM Socket 2 DIMM Socket 3 DIMM Socket 4
Memory Type Size Type Size Type Size Type Size
64 MB 2 x 72 16 MB 2 x 72 16 MB 2 x 72 16 MB 2 x 72 16 MB
64 MB 4 x 72 32 MB 4 x 72 32 MB – – – –
64 MB 4 x 72 32 MB 2 x 72 16 MB 2 x x72 16 MB – –
64 MB 8 x 72 64 MB – – – – – –
96 MB 8 x 72 64 MB 4 x 72 32 MB – – – –
96 MB 8 x 72 64 MB 2 x 72 16 MB 2 x 72 16 MB – –
96 MB 4 x 72 32 MB 4 x 72 32 MB 2 x 72 16 MB 2 x 72 16 MB
128 MB 8 x 72 64 MB 4 x 72 32 MB 2 x 72 16 MB 2 x 72 16 MB
128 MB 8 x 72 64 MB 4 x 72 32 MB 4 x 72 32 MB – –
128 MB 8 x 72 64 MB 8 x 72 64 MB – – – –
128 MB 16 x 72 128
MB – – – – – –
192 MB 8 x 72 64 MB 8 x 72 64 MB 4 x 72 32 MB 4 x 72 32 MB
192 MB 8 x 72 64 MB 8 x 72 64 MB 8 x 72 64 MB – –
192 MB 16 x 72 128
MB 4 x 72 32 MB 2 x 72 16 MB 2 x 72 16 MB
192 MB 16 x 72 128
MB 4 x 72 32 MB 4 x 72 32 MB – –
192 MB 16 x 72 128
MB 8 x 72 64 MB – – – –
256 MB 8 x 72 64 MB 8 x 72 64 MB 8 x 72 64 MB 8 x 72 64 MB
256 MB 16 x 72 128
MB 8 x 72 64 MB 8 x 72 64 MB – –
256 MB 16 x 72 128
MB 16 x
72 128
MB – – – –
256 MB 32 x 72 256
MB – – – – – –
384 MB 16 x 72 128
MB 16 x
72 128
MB 8 x 72 64 MB 8 x 72 64 MB
Important!
You can use 8-MB, 16-MB,
32-MB, 64-MB, 128-MB,
256-MB, and 512-MB
DIMMs in any combination,
bank, or order to expand the
SDRAM up to 2 GB.
