Fiber Multi-mode connector types supported:

Fiber Port, ST-type (twist-lock): Fiber multi-mode, 10Mb 10BASE-FL

Fiber Port, MTRJ-type (plug-in): SFF Fiber multi-mode100BASE-FX

Fiber Port, SC-type (snap-in): Fiber optic multi-mode, 100BASE-FX

Fiber Port, ST-type (twist-lock): Fiber optic m.-mode, 100BASE-FX

Fiber Port, 1000BASE-FX, GBIC modules

Fiber Single-mode connector types:

Fiber Port, SC-type: Fiber optic single-mode, 100BASE-FX

Fiber Port, LC-type Fiber optic SFF single-mode, 100BASE-FX

Fiber Port, 1000BASE-FX, GBIC modules

LEDs: Per Port (one set at the port, one set on rear top)

LK:

Steady ON when media link is operational

ACT: ON with receiver port activity

FDX/HDX: ON = Full-Duplex Mode

OFF = Half-Duplex Mode

100/10: ON = 100Mbps speed

OFF = 10 Mbps

Operating

Environment

Ambient Temperature:

-40

° to 140° F (-40° to 60°C) for UL60950 and Component Parts rating

-60

° to 205° F (-50° to 95°C) for IEC 60068 Type Test short-term rating

Storage Temperature: -60

°to 210°F (-50°to 100°C)

Ambient Relative Humidity: 5% to 95% (non-condensing)

Altitude: -200 to 13,000 ft. (-60 to 4000m)

Conformal Coating (humidity protection) option: Request quote

Alarm Relay Contacts

One NC indicating internal power, one NC software controllable


Packaging

Enclosure: Rugged High strength sheet metal.
Dimensions: 9.8 in. H x 5.90 in. W x 3.70 in. D

24.9 cm H x 15.0 cm W x 9.4 cm D

Cooling method: Convection, fully –enclosed elongated dual-cavity case

used as heat-sink. designed for vertical mounting, no fans

Weight: 2.1 lbs. (0.95 kg)

Management Console connector

DB-9 for RS-232 “null-modem” cable (sometimes called an X-modem cable)

Power Supply (Internal)

AC Power Connector: IEC-type, male recessed at rear of chassis,

Input Voltage: 100 to 240 VAC (auto-ranging)

Input Frequency: 47 to 63 Hz (auto-ranging)

Power Consumption:

25 watts typical (for a fully loaded fiber model)

15 watts typical (for a 8-port copper only model)
