Magnum 6K8-Series Industrial Field Switch Installation and User Guide (04/07)
49
www GarrettCom com
.
.
5.0
Introduction - Magnum 6K8 Industrial Field Switch Port Modules
This chapter describes each Port Module (PM), including appearance,
functionality, and status displays.
5.1
Inspecting the Package and Product
This section applies only to PMs shipped as separate items, i.e., if 6K8 PMs not
factory installed in a Magnum 6K8 PM slot.
Examine the shipping container for obvious damage prior to
installing a 6K8 PM; notify the carrier of any damage you believe occurred
during shipment or delivery. Inspect the contents of this package for any signs
of damage and ensure that the items listed below are included.
This package should contain:
1 6K8-Series (6K8- series KPMVs)
Installation instructions, with illustrations
Remove the 6K8-Series PM(s) from the shipping container. Be sure
to keep the shipping container should you need to ship any of the PMs
separately at a later date. In the event there are items missing or damaged,
contact your supplier. If you need to return the unit, use the original shipping
container if possible. Refer to Chapter 5 for specific return procedures.
5.2
6KPMV Module Description
An important feature of the Magnum 6K8-Series is the use of Port Modules for
flexible mixed-media connectivity to RJ-45 and fiber media. Since the Magnum
6K8-Series Switches have dual-speed capability for copper ports, the 2, 4, 6 or
8-port interfaces are designed to support all standard Ethernet media types at 10
or 100 or 1000Mps speed. Each 6K8-Series PM provides a wide selection of
connecting Ethernet media segments with all similar or combo connector type.
Note: The 6K8V Port modules are exactly similar in the functions, size and price,
compared to 6K8- but addressed as e.g. 6KP8V-RJ45. For a correct list of
6K8 Port Module types, refer to Section 1.2
Each 6K8-Series PM is individually described in the following sections.
NOTE: The 10/100 RJ-45 ports on all the modules, either all
RJ-45 ports or used for COMBO module are featured with
Auto-negotiation and Auto-Cross (MDIX).
