Magnum 6K8-Series Industrial Field Switch Installation and User Guide (04/07)
6
www GarrettCom com . .
6KP5V-G4RJ “G+4” modules, with one GBIC receptacle for one user selectable
GBIC transceiver (see below) with 4 fixed 10/100 RJ-45 ports.
6KP3V-G2SC “G+2” module, with one GBIC receptacle for one user selectable GBIC
transceiver (see below) and 2 100Mb 2km FX SC fiber ports.
GBPMV-2OTX Two-port Gigabit module for 6K8-Series Switches, with two GBIC
receptacles for user selectable GBIC transceivers (see below).
GBPMV-COTX One slot Gigabit module for 6K8-Series Switches, with one GBIC
receptacle for a user selectable GBIC transceiver module (see below).
GBIC(1000Mb) Transceiver options for Mangum 6K8-Series
GBIC-SXSC One 1000BASE-SX port with 850nm multi mode SC fiber connector
GBIC-LXSC10 One 1000BASE- LX/LH port with 1310nm single mode SC (10km)
fiber connector
GBIC-LXSC25 One 1000BASE- LX/LH port with 1310nm single mode SC (25km)
fiber connector
GBIC-ZXSC40 One 1000BASE-ZX port with 1550nm, single mode SC (40km) fiber
connector
GBIC-ZXSC70 One 1000BASE-ZX port with 1550nm, single mode SC (70km) fiber
connector
GBIC-TP One 802.3ab 1000BASE-T port, RJ-45 connector
CONSOLE CBL Industry standard serial cable, DB-9 connectors for RS-232 “ null-
modem “ connection (sometimes called an X-modem cable), used to connect a PC or a
character terminal to the Management port.
CONSOLE USB Industry standard serial cable, DB-9 connectors for RS-232 “ null-
modem “ connection (sometimes called an X-modem cable) to connect to a managed
switch, and a USB port to connect to a PC
DIN-RAIL-VRM DIN-Rail holder for a secure vertical mount of a 6K8-Series unit,
with screws to attach to metal mounting brackets of the 6K8 case.
GarrettCom, Inc. reserves the right to change specifications, performance
characteristics and/or model offerings without notice.
