1.2 Ordering Information
Magnum Industrial Field Switch (8 ports max)
MODEL DESCRIPTION
Magnum 6K8 -Managed Industrial Field Switch, base unit for vertical mounting.
Worldwide AC power. May be configured with a selection of 10/100/1000 fiber and
copper port connector types, 8 total ports max. for 10/100Mbps or 2 ports maxm for
Gigabit ports. Two metal brackets for vertical wall or panel mounting. Wire speed
filtering and forwarding across all ports, 802.3x flow control, 802.1p priority packet
processing, self-learning 4K-node address table, large 240KB packet buffers for 10/100
and 120KB for 1000Mb. For licensed managed networks software (MNS-6K and S-ring),
See separate data sheets.
Magnum 6K8 -24VDC: Same as 6K8 except the power input is 24VDC
Magnum 6K8 -5VDC: Same as 6K8 except the power input is regulated 5VDC & fused
Magnum 6K8-48VDC: Same as 6K8 except the power input is –48VDC
Magnum 6K8-125VDC: Same as 6K8 except the power input is 125VDC
Configuration Options:
Each Magnum 6K8 base unit has one port module slot which can be equipped with
one of the following single or multi-mode fiber, copper, 1000, 100 or 10Mbps modules.
Magnum 6K8 Port Modules
6KP8V-RJ45 TP Module, with 8x10/100Mbps auto-negotiating RJ-45 ports
6KP8V-MTRJ SFF Fiber modules, with 8x100Mb mm FX MT-RJ connectors
6KP8V-MLC SFF Fiber modules, with 8x100Mbps mm FX LC connectors
6KP8V-SLC SFF Fiber modules, with 8x100Mbps single-mode FX LC connectors
6KP4V-FXSC “2+2” 100Mb Fiber module, with 4x100Mb 2km FX SC connectors
6KP4V-FXST “2+2” 100Mb Fiber module, with 4x100Mb 2km FX ST connectors
6KP4V-F10ST “2+2” 10Mb Fiber module, with 4x10Mb 2km FL ST connectors
6KP4V-FLSTFX “2+2” ST Fiber module, with 2x100Mb & 2x10Mb ports, 2km
6KP8V-45-2MT “6+2” module, with 6xRJ-45 ports and 2x100Mb 2km FX MTRJ
6KP8V-45-2SLC “6+2” module, with 6xRJ-45 ports and 2x100Mb s.m 15km FX LC
6KP8V-45MT “4+4” module, with 4xRJ-45 ports and 4x2km mm FX MTRJ
6KP8V-45MLC “4+4” module, with 4xRJ-45 ports and 4x2km mm LC connectors
6KP8V-45SLC “4+4” module, with 4xRJ-45 ports and 4x2km single mode LC
6KP6V-RJMST “4+2” module, with 4xRJ-45 ports and 2x2km mm FX ST
6KP6V-RJMSC “4+2” module, with 4xRJ-45 ports and 2x2km mm FX SC
6KP6V-RJSSC “4+2” module, with 4xRJ-45 ports and 2x20km single.mode FX SC
6KP6V-RJSSCL “4+2” module, with 4xRJ-45 ports and 2x40km single mode FX SC
6KP6V-MT10ST “4+2” module, with 4xMTRJports and 2x10Mb 2km FL ST
6KP6V-RJ10ST “4+2” module, with 4xRJ-45 ports and 2x10Mb 2km FL ST
