Magnum 6K8-Series Industrial Field Switch Installation and User Guide (04/07)
10
www GarrettCom com . .
convection cooling (no fans), the Magnum 6K8 easily qualifies for use in transportation
and traffic control systems, power utilities and industrial factory-floors. For the fast
growing demands of video surveillance systems with segments requiring Gigabit
backbone interconnections, the Magnum 6K8 managed switches are easy to install and
operate with Magnum 6K management firmware.
The advanced generation of industrial applications requires advanced managed network
software, operation at extended
temperatures, fiber ports modularity,
support for self-healing ring structures,
redundancy, security and gigabit backbone
configurability. The Magnum 6K8 has all
of these, in a very tough and robust metal
case with a wide choice of popular DC
options or industry standard AC internal
input.
The plug-n-play Magnum 6K8 Industrial Field switches, should be mounted vertically
using the vertical mounting brackets which come
along with the unit or by using the DIN-RAIL-KIT
(optional) for Din rail mounting.
Loaded with versatile and secured management
software (MNS-6K), the 6K8 switch can be easily
managed and monitored via SNMP or secured Web.
Supporting dual Gigabit ports (copper or fiber) in
one slot defines the Magnum 6K8 Field switches
role as an effective Managed Gigabit media converter Switch that meets any secured
Gigabit media requirements.
Dual LEDs on the front and side help the vertically mounted 6K8 to be monitored easily.
The modular designed Magnum 6K8 Industrial Field switch can support a maximum of
two Gigabit modules (fiber or copper) to meet any demand of bandwidth-required
applications. In an on-going demand of diversified designed Ethernet applications, the
Magnum 6K8 is a fine solution to meet and satisfy any requirements through its rich
modular structure. The Relay contact for external “ALARM” is another additional
