COMMREQ Status Word:
The Ethernet Interface updates the CRS word to show success
or failure of the command. Command words 3 and 4 specify the PLC memory location
of the CRS word.
(Word 3) COMMREQ Status Word Pointer Memory Type:
This word specifies the memory
type for the CRS word. The memory types are listed in the table below.
ББББ
ББББ
ББББ
Type
БББББ
БББББ
БББББ
Value
(Decimal)
ББББ
ББББ
ББББ
Value
(Hex.)
БББББББББББББББББ
БББББББББББББББББ
БББББББББББББББББ
Description
ББББ
ББББ
%R
БББББ
БББББ
8
ББББ
ББББ
08h
БББББББББББББББББ
БББББББББББББББББ
Register memory (word mode)
ББББ
ББББ
%AI
БББББ
БББББ
10
ББББ
ББББ
0Ah
БББББББББББББББББ
БББББББББББББББББ
Analog input memory (word mode)
ББББ
ББББ
%AQ
БББББ
БББББ
12
ББББ
ББББ
0
Ch
БББББББББББББББББ
БББББББББББББББББ
Analog output memory (word mode)
ББББ
ББББ
ББББ
%I
БББББ
БББББ
БББББ
16
70
ББББ
ББББ
ББББ
10h
46h
БББББББББББББББББ
БББББББББББББББББ
БББББББББББББББББ
Discrete input memory (byte mode)
Discrete input memory (bit mode)
ББББ
ББББ
ББББ
%Q
БББББ
БББББ
БББББ
18
72
ББББ
ББББ
ББББ
12h
48h
БББББББББББББББББ
БББББББББББББББББ
БББББББББББББББББ
Discrete output memory (byte mode)
Discrete output memory (bit mode)
ББББ
ББББ
ББББ
%T
БББББ
БББББ
БББББ
20
74
ББББ
ББББ
ББББ
14h
4Ah
БББББББББББББББББ
БББББББББББББББББ
БББББББББББББББББ
Discrete temporary memory (byte mode)
Discrete temporary memory (bit mode)
ББББ
ББББ
%M
БББББ
БББББ
22
76
ББББ
ББББ
16h
4Ch
БББББББББББББББББ
БББББББББББББББББ
Discrete momentary internal memory (byte mode)
Discrete momentary internal memory (bit mode)
ББББ
ББББ
ББББ
%G
БББББ
БББББ
БББББ
56
86
ББББ
ББББ
ББББ
38h
56h
БББББББББББББББББ
БББББББББББББББББ
БББББББББББББББББ
Discrete global data table (byte mode)
Discrete global data table (bit mode)
(Word 4) COMMREQ Status Word Pointer Offset:
This word contains the offset within
the memory type selected. The status word pointer offset is a zero-based number. For ex-
ample, if you want %R1 as the location of the CRS word, you must specify a zero for the
offset. The offset for %R100 would be 99. Note, however, that this is the only zero-
based field in the Channel commands.
For information on the contents of the COMMREQ Status word, see Section 4.
(Word 5):
Reserved. Set to zero.
(Word 6):
Reserved. Set to zero.
(Words 7 - 31) Data Block:
The Data Block defines the Channel command to be per-
formed. For information on how to fill in the Channel command information, see Sec-
tion 3.
