6
6-6 TCP/IP Ethernet Communications User’s Manual – January 1996 GFK-1004B
The operator must correct the fault forcing entry into this state before the Ethernet
Interface may proceed. In most cases this may be done by using the Logicmaster 90-70
Configurator or the Station Manager CHSOSW command. It cannot be performed
remotely from the network. After entering new Soft Switch information or correcting
another fault, the Ethernet Interface must be restarted to begin using these new values.
In the Soft Switch Entry state, a NODE command to the Station Manager will yield a
“Soft Switch Entry Utility” message following the station identification information; also,
the Station Manager prompt is an asterisk (“*”).
Table 6-3. Soft Switch Entry State
БББББББ
БББББББ
LED БББББББББ
БББББББББ
Soft Switch Entry State
БББББББ
БББББББ
MODULE OK
БББББББББ
БББББББББ
Slow Blink
БББББББ
БББББББ
ONLINE
БББББББББ
БББББББББ
OFF
БББББББ
БББББББ
STATUS OK
БББББББББ
БББББББББ
OFF
Slow Blink = Blink ON every 2 seconds.
The Field Network Test State
The Field Network Test state is selected by entering a “F” or “f ” in response to the “@”
prompt at the local Station Manager terminal at the end of power-up diagnostics. The
“f ” will not be echoed back. A limited subset of Station Manager commands is provided
in this state. Refer to Chapter 5, “Field Network Test Utility” for a detailed description of
the Field Network Test state and to Chapter 2, “Installation Procedure 5 - Testing the
Ethernet Interfaces on the Network” for an application. The table below shows the LED
patterns for Field Network Test State.
In the Field Network Test State, a NODE command to the Station Manager will indicate
“Field Network Test Utility”. The Station Manager prompt is a dollar sign (“$”).
Table 6-4. Field Network Test State
БББББББББ
БББББББББ
LED
БББББББББББ
БББББББББББ
Connected to LAN БББББББББ
БББББББББ
Not Connected to LAN
БББББББББ
БББББББББ
БББББББББ
LED
ББББББ
ББББББ
ББББББ
Operating w/o
Exceptions
ББББББ
ББББББ
ББББББ
An Exception
has Occurred БББББББББ
БББББББББ
БББББББББ
Not Connected to LAN
БББББББББ
БББББББББ
MODULE OK
ББББББ
ББББББ
ON
ББББББ
ББББББ
ON
БББББББББ
БББББББББ
ON
БББББББББ
БББББББББ
ONLINE
ББББББ
ББББББ
ON/Blink 1
ББББББ
ББББББ
ON/Blink 1
БББББББББ
БББББББББ
OFF
БББББББББ
STATUS OK
ББББББ
ON
ББББББ
OFF 2
БББББББББ
OFF 2
1. ONLINE blinking indicates this node is sending or receiving data.
2. When MODULE OK is ON and STATUS OK is OFF, it is necessary to use the Station Manager
NODE, LOG, and SOSW commands to distinguish among the possible causes.
