GE GEFanuc Automation Programmable Control Products TCP/IP Ethernet Communications for the Series 90t-70 PLC GFK-1004B - Manual (Page 163)

5
5-36 TCP/IP Ethernet Communications User’s Manual – January 1996 GFK-1004B
TALLY Command
The TALLY command has the form:
TALLY
where is one or more task identification letters from Table 5-3
This command causes the current value of the tallies for the specified task or tasks to be
displayed. Some of these tallies simply indicate load and performance information
about the station. Others can indicate whether or not there are problems either within
the station or within the network. See Chapter 5, Troubleshooting, for more information
on using the tallies to help isolate and resolve problems.
An example TALLY command is shown below:
> tally c
<<< PLC Driver Tallies >>>
PlcQFull = 0000H PlcSweep = 03c9H MsgRcv = 0038H PLCReq = 001aH
PlcAbt = 0000H MsgSent = 0036H MyAbt = 0000H Write = 0023H
Read = 0010H Timeout = 0000H Regs = 0400H AnInput = 0040H
AnOutput = 0040H uCode = 0300H
Table 5-11. PLC Driver Tallies (Tally c)
БББББББ
БББББББ
Tally
БББББББББББББББББББ
БББББББББББББББББББ
Meaning
БББББББ
БББББББ
PlcQFull
БББББББББББББББББББ
БББББББББББББББББББ
Count of the number of times a request of the PLC was retried be-
cause of congestion in the PLC.
БББББББ
БББББББ
БББББББ
PlcSweep БББББББББББББББББББ
БББББББББББББББББББ
БББББББББББББББББББ
Count of the number of executive windows received by the Ethernet
Interface.
БББББББ
MsgRcv
БББББББББББББББББББ
Count of the number of messages received from the CPU.
БББББББ
БББББББ
БББББББ
PlcReq БББББББББББББББББББ
БББББББББББББББББББ
БББББББББББББББББББ
Count of the number of COMMREQs received from the application
program.
БББББББ
PlcAbt
БББББББББББББББББББ
Count of the number of times the CPU aborted a data transfer.
БББББББ
БББББББ
MsgSent БББББББББББББББББББ
БББББББББББББББББББ
Count of the number of messages sent to the CPU.
БББББББ
БББББББ
MyAbt
БББББББББББББББББББ
БББББББББББББББББББ
Count of the number of times the Ethernet Interface aborted a data
transfer.
БББББББ
БББББББ
БББББББ
Write БББББББББББББББББББ
БББББББББББББББББББ
БББББББББББББББББББ
Count of the number of times the Ethernet Interface successfully
wrote to the PLC memory.
БББББББ
БББББББ
Read
БББББББББББББББББББ
БББББББББББББББББББ
Count of the number of times the Ethernet Interface successfully read
from the PLC memory.
БББББББ
БББББББ
Timeout
БББББББББББББББББББ
БББББББББББББББББББ
Count of the number of times the Ethernet Interface timed out wait-
ing for a response from the CPU.
БББББББ
БББББББ
uCode БББББББББББББББББББ
БББББББББББББББББББ
The microcode revision level of the firmware in the CPU.
