Chapter 5 The Station Manager
mand. All arguments to the commands, will be automatically converted to all lower case
characters unless they are enclosed in double quotation marks (e.g., “A”).
Task Identification
Several commands refer to “tasks” or subsystems of the operating software. Each task
has a unique identifying letter which is used to select the desired task or tasks. The fol-
lowing table shows the task identifiers and their associated tasks.
Table 5-3. Task Identifiers
БББББ
БББББ
Identifier
БББББББББ
БББББББББ
Task
БББББ
b
БББББББББ
System Memory
БББББ
БББББ
c
БББББББББ
БББББББББ
PLC Driver
БББББ
БББББ
f
БББББББББ
БББББББББ
ARP
БББББ
БББББ
h
БББББББББ
БББББББББ
Channel API
БББББ
БББББ
i
БББББББББ
БББББББББ
IP Layer
БББББ
БББББ
j
БББББББББ
БББББББББ
ICMP
БББББ
l
БББББББББ
Data Link Layer
БББББ
БББББ
v
БББББББББ
БББББББББ
SRTP Server Agent
БББББ
БББББ
w
БББББББББ
БББББББББ
TCP Layer
Display Data Representation
The data that is displayed by the Station Manager is formatted in one of several ways
depending on the type of data being input or output.
Note
The Ethernet Interface has a limited output buffer for storing Station
Manager command results. If a command’s output exceeds this size,
part of the command output will be lost, and will not be displayed.
Numeric Values
Numeric values are displayed as decimal values with the hexadecimal equivalent
printed in parenthesis beside it. An exception is baud rate which are printed only in dec-
imal. Hexadecimal values are represented with a “H” as their last character.
An example of numeric output is shown below.
bbuff4 = 2140 (085cH)
When numeric values are entered, they may be entered as either a decimal value or as a
hexadecimal value. Hexadecimal values must be entered using the trailing “H” (either
upper or lower case) as their last character.
