Serial

16 kB

Type

RS 232 C; RS 422; RS 485
or Current loop

Baudrate

110; 150; 300; 600; 1200;
2400; 4800;9600;19200;
38400

Data format

7 bit / 8 bit

1)

Parity bit

even, odd, mark, space, no

1)

Safety

acc. to EN 61010-1:2001
CAT III > 150 V

300 V

pollution degree 2

DC

10 V ... 19 V
approx. 20 VA

2)

19 V ... 36 V
approx. 18 VA

2)

AC

85 V ... 265 V , 45 - 65 Hz,
approx. 15 W
switch-mode power supply

Storage temperature range

-20 °C to +60 °C

Operating temperature range 0 °C to +45 °C
Climate

relative humidity < 80 %
up to 31 °C

Protection type

acc. to EN 60529/VDE 0470

housing

IP 50

terminals

IP 00

Insulation group

C acc. to VDE 0110

Mech. strength

acc. to IEC 1010

EMC
Emission

EN 55011, Class A
EN 55022, Class B

Susceptibility

EN 61000-4-2 B
EN 61000-4-3 A
EN 61000-4-4 B

1)

See setting transmission parameters of the sender at page 9.

2)

Starting current approx. 1,2 A (10 V ... 19 V) or approx. 0,8 A
(19 V ... 36 V).
This value can be used to rate the external fuse.

Input buffer

Serial
Interface I

Voltage
supply

Ambient
conditions

Standards

CE

7
