2. Technical data
Motor with friction clutch, electronic lag 3 sec
Paper width: max. 80 mm
Paper length: max. 15 m
Store temperature range: -20 °C to +80 °C
Operating temperature range: 0 °C to +70 °C
Climate: relative humidity
< 80 % up to 31 °C
Protection type housing: IP 50 acc. to
EN 60528/VDE 0470
Mech.strength: To IEC 1010
Safety: EN 61010-1:2001
CATIII >150V
≤ 300V
Pollution degree 2
EMC
Susceptibility:
DIN EN 610004-1
to EN 610004-4
Emission: DIN EN 50081-2
Class B
Dimensions (WxHxD): 144 x 72 x 159 mm
Connector: MASCON female
multi point connector,
4 pin keyed
Connector cable: AWG 26,
approx. 100mm
Power supply: by IPP (5 V DC)
CE
The torque of the friction clutch has been factory adjusted
and should not require adjustment.
The winding force of the motor can be adjusted by slightly
rotating the screw accessible through the left hand side
hole in the body:
➨ ➨ ➨ ➨ ➨
less = turn left
➨ ➨ ➨ ➨ ➨ more = turn right
59
Winding
Ambient
conditions
Standards
Miscellaneous
Connection
Maintenance
friction
clutch
