Voltage supply Screw type/terminals
fixed:
0,2 to 4 mm²
flexible: 0,2 to 2,5 mm²
AWG: 24 to 12
Interface I 9pin D-Sub socket
Interface II 9 pin D-Sub socket
or
USB-B socket
Connection for paper
reroll mechanism
4pin MASCON, MLAS
Connection for
Alarm relay output
Screw type/terminal
fixed:
0,2 to 4 mm²
flexible: 0,2 to 2,5 mm²
AWG: 24 to 12
normally open
50 V AC, 2 A
30 V DC, 2 A
Dimensions
(W x H x D)
144 x 72 x 159 mm
Switchboard mounting screws against rear side
of switchboard
Internal fuse
( on power supply board)
12V DC : T 3,15 A
24V DC : T 2 A
110V - 230V AC : T 2 A
This operating manual applies to software version
5.01.05 and higher
Connections
Miscellaneous
