This mode can be used to print a group of texts, triggered by a
single input, even if no variable data is required to be
inserted.
NOTE: Text No. 7 is only pre-programmed with a variable data field.
56
8.5. Examples for Automatic text Insert mode
Example 1:
Consignment
print-out, with
time & date,
marks and
weights Data input:
10:15:33 15/10/03 1 123 1 1027 997 30
Actual Print-out: Pre-stored texts
(„
✴ “ = spaces reserved for
variable data)
10:15:33 15/10/03 1 ✴✴✴✴✴✴
Product Ref: 123 2 Product Ref: ✴✴✴✴✴✴
Operator No: 1 3 Operator No: ✴✴✴✴✴✴
Gross: 1027 kg 4 Gross: ✴✴✴✴✴✴
Nett: 997 kg 5 Nett: ✴✴✴✴✴✴
Tare: 30 kg 6 Tare: ✴✴✴✴✴✴
Six blocks of data are inserted and printed in sequence.
In this example, the IPP..GE automatically adds date & time from
its own real-time clock using the „PRINT DATE / TIME-HEADLINE“
menu option. Four blocks of variable data are sent to the printer.
Data input: 115 33.7 62.8 228.7
Actual Print-out: Pre-stored texts
13.10.03 13:49:52
Metrix Electronics Ltd. 1 Metrix Electronics Ltd.
Rankine Road, Daneshill West 2 Rakine Road, Daneshill West
GB-Basingstoke RG24 8PP 3 GB-Basingstoke RG24 8PP
4
Test Number: 115 5 Test Number: ✴✴✴✴✴✴
- - - TEST RESULTS - - - 6 - - - TEST RESULTS - - -
Ambient Temp 33.7 °C 7 Ambient Temp ✴✴✴✴✴✴ °C
Burn-in Temp 62,8 °C 8 Burn-in-Temp ✴✴✴✴✴✴ °C
Nom. Supply 230 Vac 9 Nom. Supply 230 Vac
Actual 228.7 Vac 10 Actual ✴✴✴✴✴✴ Vac
Example 2:
Quality test
print-out, with
several
measured
value
Actual Printout: Pre-stored texts
15.10.03 10:34:53
Manufactured by:: 1 Manufactured by:
2
Metrix Electronics Ltd. 3 Metrix Electronics Ltd.
Rankine Road, Daneshill West 4 Rankine Road, Daneshill West
GB-Basingstoke RG24 8PP 5 GB-Basingstoke RG24 8PP
__________________ 6 _________________
7 ✴✴✴✴✴✴
All the texts up to Text No. 6 (without variable fields) are printed. Text No. 7
(the first variable field) just prints a blank line. (If there was any variable
data sent before the this would be inserted and printed here.)
Example 3:
A simple way
to print a
group of texts
