2 - 26
MITSUBISHI PLC • 3
(QnH series CPU)
Connection
Connect to the QnH series CPU.
The communication parameter setting of POD is done automatically.
Available PLC
When the CPU is updated, or the specifications are changed, there is some
possibility that POD cannot be connected to the PLC.
9
PLC Select PLC Type
QnH(Q) series CPU
QnH(A) series CPU Q06H-A
RS-232C [UG00C-Q]
or
[Wiring Diagram 1]
Wiring Diagram
Q02,
Q02H,
Q06H,
Q12H,
Q25H
* 1
*1 About the ladder transfer function, refer to Appendix.
