Fujitronic Programmable Operation Display UG520H-x User Manual
Page 108
2 - 39
13 OMRON PLC
•
1
Bank No.
Address No.
Colon
Available Memory
*
1
When using EMn (extensional data memory), specify the bank
number (CV: 0 to 7, CS1: 0 to C).
The assigned memory is indicated while editing the screen as
illustrated:
Set the memory to the extent of the memory range of each PLC model.
Use TYPE number to assign indirect memory for macro programs.
CV
Memory
TYPE
Remarks
DM (data memory)
0
CH
(input/output relay)
1
AR
(alarm relay)
4
T
(timer/current value)
5
C
(counter/current value)
6
EMn (extensional data memory)
7
*1
TU
(timer/contact)
9
Read only
CU
(counter/contact)
10
Read only
CS1
Memory
TYPE
Remarks
DM (data memory)
0
CH
(input/output relay)
1
H
(holding relay)
2
A
(alarm relay)
4
T
(timer/current value)
5
C
(counter/current value)
6
EMn (extensional data memory)
7
*
1
W
(Internal Relay)
8
TU
(timer/contact)
9
Read only
CU
(counter/contact)
10
Read only
C
Memory
TYPE
Remarks
DM (data memory)
0
CH
(input/output relay)
1
HR
(holding relay)
2
LR
(latch relay)
3
AR
(alarm relay)
4
T
(timer/current value)
5
C
(counter/current value)
6
EMn (extensional data memory)
7
*1
TU
(timer/contact)
9
Read only
CU
(counter/contact)
10
Read only
