2 - 6
FUJI PLC • 3
(MICREX-SX CPU Port)
Available PLC
* When the CPU is updated, or the specifications are changed, there is some possibility that POD
cannot be connected to the PLC.
Communication Setting
Connect to the CPU port. The communication parameter setting of POD is done automatically.
Available Memory
To specify a memory, basically a variable name is set. For the variable name linkage function, refer to the
User’s Manual (FEH363).
Set the memory to the extent of the memory range of each PLC model.
Use TYPE number to assign indirect memory for macro programs.
To set an indirect memory using a macro, specify the CPU No. using the extended code.
Indirect memory setting by macro is not available for input (I) or output (Q) memory.
3
PLC
MICREX-SX Loader Port
Select PLC Type
MICREX-SX
CPU
UG00C-Sx
Connected Cable
38400bps
RS-422
Even Even
RS-422 Transmission Control Mode
Baud Rate
Parity
Data Length
Stop Bit
Item Setting of PLC
38400bps
8 8
1 1
Transmission
Code
Comm. Parameter of POD
2 FUJI PLC • 3
Standard Memory TYPE Remarks
I (input memory) -
O (output memory) -
M (standard memory) 2
RM (retain memory) 4
SM (system memory) 8
