1 - 13
Dimensions and Panel Cut-out
5
Dimensions of UG220
Panel Cut-out of UG220
131
174 +0.5
- 0
+0.5 - 0
Unit : mm
CN2
CN1
MJ2 MJ1
173.6
182.5
117.2
138.8 88.4 130.8
45
5
Top View
Unit : mm
Rear View
Front View Side View
5 Dimensions and Panel Cut-out
