Page 126: Fa-500), Available plc communication setting
2 - 57
20
YOKOGAWA PLC • 1
(FA-500)
Available PLC
Communication Setting
The recommended communication parameter setting of both PLC and POD is as follows:
Available Memory
Set the memory to the extent of the memory range of each PLC model.
Use TYPE number to assign indirect memory for macro programs.
Port
1
19200bps
Even
7
Baud Rate
Parity
Transmission
Code
Data Length
Stop Bit
1
Sumcheck
Terminal Character
Item
Setting of PLC
1
19200bps
Even
7
1
Protection Function
Comm. Parameter of POD
Provided (fixed)
None (fixed)
None (fixed)
FA500
FA500
LC01-0N
PLC
Link Unit
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 2]
RS-232C [Wiring Diagram 1]
LC02-0N
Select PLC Type
Wiring Diagram
20 YOKOGAWA PLC
•
1
Memory
TYPE
Remarks
D
(data register)
0
B
(common register)
1
TP
(timer/current value)
2
TS
(timer/set value)
3
CP
(counter/current value)
4
CS
(counter/set value)
5
X
(input relay)
6
Y
(output relay)
7
I
(internal relay)
8
E
(external relay)
9
