FANUC PLC
44
Port 0 (fixed)
19200bps (fixed)
Even (fixed)
8 (fixed)
Baud Rate
Parity
Transmission
Code
Data Length
Stop Bit 1 (fixed)
Item Setting of PLC
RS-422 (fixed) Signal
Comm. Parameter of POD
PLC
Port of CPU unit (JD14)
of Power Mate-Model H/D
Select PLC Type
Power Mate
RS-422 [Wiring Diagram 2]
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 3]
Power Mate i Model H/D
Wiring Diagram
Available PLC
Communication Setting
The recommended communication parameter setting of both PLC and POD is as follows:
Available Memory
Set the memory to the extent of the memory range of each PLC model.
Use TYPE number to assign indirect memory for macro programs.
Memory TYPE Remarks
D (data register) 0
X (input relay) 1 WX as word data
Y (output relay) 2 WY as word data
R (internal relay) 3 WR as word data
K (keep relay) 4 WK as word data
T (timer) 5
C (counter) 6
