Page 79: Input
FS-2/2E Studio DTE Disk Recorder User Guide
59
2.5.12.7 Audio Input
In this submenu, you can change the default audio input linked to
a particular video input.
Select the mode to activate it.
1.
Press
SEL
for the highlighted menu item to open the sub-
menu. In the sub-menu, the currently highlighted mode is
the current mode after exit.
2.
Press
EXIT
to return to the menu screen. These settings are
saved on power down.
Each video input and its available audio inputs are listed below:
•
Composite
•
Analog Balanced Audio (default)
•
AES/EBU Digital Audio
•
Y/C (S-Video)
•
Analog Balanced Audio (default)
•
AES/EBU Digital Audio
•
Component
•
Analog Balanced Audio (default)
•
AES/EBU Digital Audio
•
SDI
•
Embedded (default)
•
Analog Balanced Audio
•
AES/EBU Digital Audio
•
DV
•
Embedded (default)
There is a
SETUP > AUDIO INPUT > SDI > EMBEDDED
submenu that provides the following options:
•
CHAN 1 and 2
•
CHAN 3 and 4
The FS-2E provides the option to select channels 1 and 2 or
3 and 4 of the embedded audio of the SDI input stream. This
is an FS-2E feature only.
COMPOSITE
Y/C
COMPONENT
SDI
EXIT
SEL
