FS-8700-19_Metasys_N2 Driver Manual Page 9 of 51
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]
4.4.2. Driver Related Map Descriptor Parameters
4.4.2.1. N2Open Map Descriptor Parameters
Column Title Function Legal Values
Node_Name Name of Node to fetch data from
One of the node names
specified in “Client Node
Descriptor” above
Data_Type Data type
If the vendor device lists a
point as BD then use
Data_Type=Byte.
If the vendor device lists a
point as ADI then use
Data_Type=Integer.
If the vendor device lists a
point as ADF then use
Data_Type=Float_Reg.
AI, AO, DI, DO,
Float_Reg, Integer, Byte
Length Length of Map Descriptor 1
Address Starting address of read block 1-256
MN2_Function*
Used to specify an N2-specific
function, e.g. COS. See
description below.
COS, Override, Release
MN2_Attribute*
Used to specify the attribute if an
attribute other than Current Value
is to be accessed. See attribute
table below
See
N2Open Attribute Table
