FS-8700-19_Metasys_N2 Driver Manual Page 31 of 51
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]
Extension Modules
Relative Item Signal Condition Read/Write Johnson Tag Description
38 FP Write XTHIA6 High alarm limit point 6
39 FP Write XTLOA6 Low alarm limit point 6
40 FP Write XTHIA7 High alarm limit point 7
41 FP Write XTLOA7 Low alarm limit point 7
42 FP Write XTHIA8 High alarm limit point 8
43 FP Write XTLOA8 Low alarm limit point 8
44 Word Read XTAIS Extension module alarms
45 FP Read XTAI1 Analog input value 1
46 FP Read XTAI2 Analog input value 2
47 FP Read XTAI3 Analog input value 3
48 FP Read XTAI4 Analog input value 4
49 FP Read XTAI5 Analog input value 5
50 FP Read XTAI6 Analog input value 6
51 FP Read XTAI7 Analog input value 7
52 FP Read XTAI8 Analog input value 8
53 FP Write XTAO1 Analog output value 1
54 FP Write XTAO2 Analog output value 2
55 FP Write XTAO3 Analog output value 3
56 FP Write XTAO4 Analog output value 4
57 FP Write XTAO5 Analog output value 5
58 FP Write XTAO6 Analog output value 6
59 FP Write XTAO7 Analog output value 7
60 FP Write XTAO8 Analog output value 8
61 LONG Write XTDIC1 Digital input 1 pulse count
62 LONG Write XTDIC2 Digital input 2 pulse count
63 LONG Write XTDIC3 Digital input 3 pulse count
64 LONG Write XTDIC4 Digital input 4 pulse count
65 LONG Write XTDIC5 Digital input 5 pulse count
66 LONG Write XTDIC6 Digital input 6 pulse count
67 LONG Write XTDIC7 Digital input 7 pulse count
68 LONG Write XTDIC8 Digital input 8 pulse count
69 Byte Write XTCNT Extension module hold control
70 Byte Write XTDO Logic outputs control and status
71 Byte Read XTDI Logic inputs status
72 Byte Read XTSTC Extension module local status
Time schedule modules
Relative Item Signal Condition Read/Write Johnson Tag Description
0 Word Write TSOPT Time schedule options LSB
1 Word Write TSEX@ External extension logical connection
2 Word Write TSON@ On forcing logical connection
3 Word Write TSOF@ Off forcing logical connection
4 FP Write TSXTM Extension time (min)
5 FP Write TSTIM Time to next event (min)
6 Byte Write TSSTA Time schedule status
