4.2. Client Side Connection Descriptions
Section Title
Connections
Column Title Function Legal Values
Port
Specify which port the device is
connected to the FieldServer
P1-P8, R1-R2
1
Protocol Specify protocol used Metasys_N2
Baud* Specify baud rate 9600
Parity* Specify parity None
Data_Bits* Specify data bits 8
Stop_Bits* Specify stop bits
1
Handshaking* Specify hardware handshaking None
Poll _Delay* Time between internal polls 0
Line_Drive_On*
Duration of RTS assert before
start of transmission
0.001s
Line_Drive_Off*
Duration of RTS assert after
end of transmission
0.000s
Example
// Client Side Connections
Connections
Port,
Protocol
R1, Metasys_N2
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
