FS-8700-19_Metasys_N2 Driver Manual

Page 43 of 51

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]

General dynamic Parameters

Relative Item Signal Condition Read/Write Johnson Tag Description
86

Byte

R/W

PM5I@3

Input Connection I3@

87

FP

R/W

PM5TYP

Options

88

FP

R/W

PM5K2

Constant K2

89

FP

R/W

PM5K3

Constant K3

90

FP

R/W

PM5K4

Constant K4

91

FP

R/W

PM5K5

Constant K5

92

FP

R/W

PM5K6

Constant K6

93

FP

R/W

PM5K7

Constant K7

94

FP

R/W

PM6K1

Constant K1 Module #6

95

Byte

R/W

PM6I@1

Input Connection I1@

96

Byte

R/W

PM6I@2

Input Connection I2@

97

Byte

R/W

PM6I@3

Input Connection I3@

98

FP

R/W

PM6TYP

Options

99

FP

R/W

PM6K2

Constant K2

100

FP

R/W

PM6K3

Constant K3

101

FP

R/W

PM6K4

Constant K4

102

FP

R/W

PM6K5

Constant K5

103

FP

R/W

PM6K6

Constant K6

104

FP

R/W

PM6K7

Constant K7

Input Output Config Parameters

Relative Item Signal Condition Read/Write Johnson Tag Description
105

Word

Read

VER

Firmware Version

106

Spare

107

Spare

108

FP

R/W

HIA1

High Alarm AI1

109

FP

R/W

LOA1

Low Alarm AI1

110

FP

R/W

HIA2

High Alarm AI2

111

FP

R/W

LOA2

Low Alarm AI2

112

FP

R/W

HIA3

High Alarm AI3

113

FP

R/W

LOA3

Low Alarm AI3

114

FP

R/W

HIA4

High Alarm AI4

115

FP

R/W

LOA4

Low Alarm AI4

116

Byte

R/W

OCN1

Output #1 Configuration

B(1)

00001 Src of Module (Analog Items 1..31)

?.

B(5)

11111

B(6)

000 = Not used

001 = Output for Solenoids

010 = 0 to 10 V Analog Output

011 = ON/OFF Output

100 = DAT Output Type

101 = PAT Output Type

B(8)

110 = Multistage ON/OFF Type

117

FP

R/W

OCO1

PAT/DAT Timing for Output Module #1

118

Byte

R/W

OCN2

Output #2 Configuration

B(1)

00001 Src of Module (Analog Items 1..31)

?.

B(5)

11111

B(6)

000 = Not used

001 = Output for Solenoids

010 = 0 to 10 V Analog Output

B(8)

011 = ON/OFF Output

119

FP

R/W

OCO2

PAT Dead Band/Multistate Hysteresis #1

120

Byte

R/W

OCN3

Output #3 Configuration

B(1)

00001 Src of Module (Analog Items 1..31)

?.
