FS-8700-19_Metasys_N2 Driver Manual Page 46 of 51
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]
Input Output Config Parameters
Relative Item Signal Condition Read/Write Johnson Tag Description
138
FP R/W LRI1 Low Range AI1
139 FP R/W FTC1 Filter Constant AI1
140 FP R/W OFS1 Offset Compensation AI1
141 Byte R/W IOP1 Analog Input Options
B(1) Controller reference
1 to 6
B(3)
B(4) Input Type: 0=volt 1=resistance
B(5) Input Mode
000 - Linear Range
001-Thermistor Linearization 2252.at 25C
010 - Square Root
011 - 0.2 suppression
100-Thermistor Linearization 10 k. at 25C
B(7) 101 - Square Root & 20 % suppression
B(8) Not used
142 FP R/W HRI2 High Range AI2
143 FP R/W LRI2 Low Range AI2
144 FP R/W FTC2 Filter Constant AI2
145 FP R/W OFS2 Offset Compensation AI2
146 Byte R/W IOP2 Analog Input Options (see IOP1)
147 FP R/W HRI3 High Range AI3
148 FP R/W LRI3 Low Range AI3
149 FP R/W FTC3 Filter Constant AI3
150 FP R/W OFS3 Offset Compensation AI3
151 Byte R/W IOP3 Analog Input Options (see IOP1)
152 FP R/W HRI4 High Range AI4
153 FP R/W LRI4 Low Range AI4
154 FP R/W FTC4 Filter Constant AI4
155 FP R/W OFS4 Offset Compensation AI4
156 Byte R/W IOP4 Analog Input Options (see IOP1)
157 Byte Write OS TC9100 Requested Operating Status
B(1) 00 = Night mode
01 = Stand-by mode
10 = Comfort mode
B(2) 11 = OFF mode
B(3) Not used
B(4) Not used
B(5) Operating Mode Toggle: Base- Alternate
B(6) Not used
B(7) Force Operating Mode
B(8) Command Module Active
158 Word Write STIME TM9100 Real Time Clk Synchronization
W(1) RTC Minutes 0..59
W(6)
W(7) Spare
W(8) Spare
W(9) RTC Hours 0..23
W(13)
W(14) RTC Day of Week 1..7
W(16)
159 Byte R/W OT@ Outdoor Temperature Connection
160 FP Write SPW Winter set point
161 FP Write SPS Summer set point
