FS-8700-19_Metasys_N2 Driver Manual Page 40 of 51
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]
Appendix D.3. Metasys TC9100 Memory Map
Note: The TC9100 is not currently supported by the FieldServer MetasysN2 Driver.
The information below is for interest and future use only.
General dynamic Parameters
Relative Item Signal Condition Read/Write Johnson Tag Description
0
Byte Read UNIT Device model. For TC-9100 always 06h
1 FP Write AI1 Process Temperature
2 FP Write AI2 Remote Temperature Set Point Bias
3 FP Write AI3 Pressure
4 FP Write AI4 Override Input
5 Spare
6 Spare
7 Spare
8 Spare
9 Word Read ADC Selected Analog Input ADC counter
10 FP Write OCM1 Output Programmable Module #1
11 FP Write OCM2 Output Programmable Module #2
12 FP Write OCM3 Output Programmable Module #3
13 FP Write OCM4 Output Programmable Module #4
14 FP Write OCM5 Output Programmable Module #5
15 FP Write OCM6 Output Programmable Module #6
16 FP Write WSP1 Working Set Point Control Module 1
17 FP Write WSP2 Working Set Point Control Module 2
18 FP Write WSP3 Working Set Point Control Module 3
19 FP Write WSP4 Working Set Point Control Module 4
20 FP Write WSP5 Working Set Point Control Module 5
21 FP Write WSP6 Working Set Point Control Module 6
22 FP Write XAI1 External Analog Input 1
23 FP Write XAI2 External Analog Input 2
24 FP Write XAI3 External Analog Input 3
25 FP Write XAI4 External Analog Input 4
26 FP Write ACO5 Analog Constant 5
27 FP Write ACO6 Analog Constant 6
28 FP Read WAC Winter Authority Correction
29 FP Read SAC Summer Authority Correction
30 Word Read ALR Analog Inputs Alarm Status
W(1) AIH1 Analog Input 1 High alarm
W(2) AIL1 Analog Input 1 High alarm
W(3) AIH2 Analog Input 2 High alarm
W(4) AIL2 Analog Input 2 Low alarm
W(5) AIH3 Analog Input 3 High alarm
W(6) AIL3 Analog Input 3 Low alarm
W(7) AIH4 Analog Input 4 High alarm
W(8) AIL4 Analog Input 4 Low alarm
W(9) Not used
W(10) Not used
W(11) Not used
W(12) Not used
W(13) Not used
W(14) Not used
W(15) Not used
W(16) Not used
31 Byte Read LOS Logic Output Status
B(1) DO3 TRIAC 3 ON
B(2) DO4 TRIAC 4 ON
B(3) DO5 TRIAC 5 ON
