FS-8700-19_Metasys_N2 Driver Manual Page 30 of 51
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]
Digital Output Modules
Relative Item Signal Condition Read/Write Johnson Tag Description
0 Byte Write DOT Digital output options
1 Word Write DO@ Source of digital output module
2 Word Write FB@ Source of feedback signal
3 Word Write DOF@ Output forcing logic connection
4 FP Write HRO Output high range
5 FP Write LRO Output low range
6 FP Write FST PAT output full stroke time/DAT cycle
7 FP Write DB PAT deadband
8 FP Write HLO Output high limit
9 FP Write LLO Output low limit
10 FP Write OFL Output % value in forcing mode
11 FP Write OUT Output module output value %
12 Byte Write DOC Logic output control and status
13 Word Write INC@ DDC increase logic connection
14 Word Write DEC@ DDC decrease logic connection
15 Word Write ENL@ Limit function enable logic connection
Extension Modules
Relative Item Signal Condition Read/Write Johnson Tag Description
0 Word Write XTIOMAP Extension module I/O map
1 Word Write XTIOTYP Extension module I/O type
2 Word Write XTIOMOD Extension module I/O mode
3 Byte Write XTADX Extension module address 0-255
4 Word Write XTI1@ Point connection - I1
5 Word Write XTI2@ Point connection - I2
6 Word Write XTI3@ Point connection - I3
7 Word Write XTI4@ Point connection - I4
8 Word Write XTI5@ Point connection - I5
9 Word Write XTI6@ Point connection - I6
10 Word Write XTI7@ Point connection - I7
11 Word Write XTI8@ Point connection - I8
12 FP Write XTHR01 High output range point 1
13 FP Write XTLR01 Low output range point 1
14 FP Write XTHR02 High output range point 2
15 FP Write XTLR02 Low output range point 2
16 FP Write XTHR03 High output range point 3
17 FP Write XTLR03 Low output range point 3
18 FP Write XTHR04 High output range point 4
19 FP Write XTLR04 Low output range point 4
20 FP Write XTHR05 High output range point 5
21 FP Write XTLR05 Low output range point 5
22 FP Write XTHR06 High output range point 6
23 FP Write XTLR06 Low output range point 6
24 FP Write XTHR07 High output range point 7
25 FP Write XTLR07 Low output range point 7
26 FP Write XTHR08 High output range point 8
27 FP Write XTLR08 Low output range point 8
28 FP Write XTHIA1 High alarm limit point 1
29 FP Write XTLOA1 Low alarm limit point 1
30 FP Write XTHIA2 High alarm limit point 2
31 FP Write XTLOA2 Low alarm limit point 2
32 FP Write XTHIA3 High alarm limit point 3
33 FP Write XTLOA3 Low alarm limit point 3
34 FP Write XTHIA4 High alarm limit point 4
35 FP Write XTLOA4 Low alarm limit point 4
36 FP Write XTHIA5 High alarm limit point 5
37 FP Write XTLOA5 Low alarm limit point 5
