FS-8700-19_Metasys_N2 Driver Manual Page 34 of 51
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]
PAGE 0
Item
DEC Item
HEX
Signal Condition Read/Write
Johnson
Tag
Description
44 2C - - Spare
45 2D - - Spare
46 2E Byte Write PV1@ Process variable connection
47 2F Byte Write RS1@ Remote setpoint connection
48 30 Byte Write RV1@ Reference variable connection
49 31 Byte Write PB1@ Proportional band connection
50 32 Byte Write OF1@ OFF mode logic control connection
51 33 Byte Write SB1@
STAND-BY mode logic control
connection
52 34 Byte Write RA1@ Reverse action logic control connection
53 35 Byte Write EF1@
External forcing logic control
connection
54 36 Byte Write TYPE1 Controller type
55 37 FP Write LS1 Local setpoint
56 38 FP Write PB1 Proportional band
57 39 FP Write TI1 Reset action
58 3A FP Write TD1 Rate action
59 3B FP Write HL1 Upper limit of the control output
60 3C FP Write LL1 Lower limit of the control output
61 3D FP Write BS1 Change of setpoint during STAND-BY
62 3E FP Write BO1 Change of setpoint during OFF
63 3F FP Write AD1 Deviation alarm
64 40 Byte Write PV2@ Process variable connection
65 41 Byte Write RS2@ Remote setpoint connection
66 42 Byte Write RV2@ Reference variable connection
67 43 Byte Write PB2@ Proportional band connection
68 44 Byte Write OF2@ OFF mode logic control connection
69 45 Byte Write SB2@
STAND-BY mode logic control
connection
70 46 Byte Write RA2@ Reverse action logic control connection
71 47 Byte Write EF2@
External forcing logic control
connection
72 48 Byte Write TYPE2 Controller type
73 49 FP Write LS2 Local setpoint
74 4A FP Write PB2 Proportional band
75 4B FP Write TI2 Reset action
76 4C FP Write TD2 Rate action
77 4D FP Write HL2 Upper limit of the control output
78 4E FP Write LL2 Lower limit of the control output
78 4E FP Write LL2 Lower limit of the control output
79 4F FP Write BS2 Change of setpoint during STAND-BY
80 50 FP Write BO2 Change of setpoint during OFF
81 51 FP Write AD2 Deviation alarm
82 52 Byte Write PV3@ Process variable connection
83 53 Byte Write RS3@ Remote setpoint connection
84 54 Byte Write RV3@ Reference variable connection
85 55 Byte Write PB3@ Proportional band connection
86 56 Byte Write OF3@ OFF mode logic control connection
87 57 Byte Write SB3@
STAND-BY mode logic control
connection
88 58 Byte Write RA3@ Reverse action logic control connection
