Programmable Module Type
Relative Item Signal Condition Read/Write Johnson Tag Description
0 Byte Write PMTYP Programmable module type
1 Word Write PMOPT Programmable module options
2 Byte Write PMF1 Function channel number 1 - F1
3 Byte Write PMF2 Function channel number 2 - F2
4 Byte Write PMF3 Function channel number 3 - F3
5 Byte Write PMF4 Function channel number 4 - F4
6 Byte Write PMF5 Function channel number 5 - F5
7 Byte Write PMF6 Function channel number 6 - F6
8 Byte Write PMF7 Function channel number 7 - F7
9 Byte Write PMF8 Function channel number 8 - F8
10 Word Write PMI1@ Input connection - I1@
11 Word Write PMI2@ Input connection - I2@
12 Word Write PMI3@ Input connection - I3@
13 Word Write PMI4@ Input connection - I4@
14 Word Write PMI5@ Input connection - I5@
15 Word Write PMI6@ Input connection - I6@
16 Word Write PMI7@ Input connection - I7@
17 Word Write PMI8@ Input connection - I8@
18 Word Write PMI9@ Input connection - I9@
19 Word Write PMI10@ Input connection - I10@
20 Word Write PMI11@ Input connection - I11@
21 Word Write PMI12@ Input connection - I12@
22 Word Write PMI13@ Input connection - I13@
23 Word Write PMI14@ Input connection - I14@
24 Word Write PMI15@ Input connection - I15@
25 Word Write PMI16@ Input connection - I16@
26 FP Write PMK01 Module constant - K1
27 FP Write PMK02 Module constant - K2
28 FP Write PMK03 Module constant - K3
29 FP Write PMK04 Module constant - K4
30 FP Write PMK05 Module constant - K5
31 FP Write PMK06 Module constant - K6
32 FP Write PMK07 Module constant - K7
33 FP Write PMK08 Module constant - K8
34 FP Write PMK09 Module constant - K9
35 FP Write PMK10 Module constant - K10
36 FP Write PMK11 Module constant - K11
37 FP Write PMK12 Module constant - K12
38 FP Write PMK13 Module constant - K13
39 FP Write PMK14 Module constant - K14
40 FP Write PMK15 Module constant - K15
41 FP Write PMK16 Module constant - K16
42 FP Write PMK17 Module constant - K17
43 FP Write PMK18 Module constant - K18
44 FP Write PMK19 Module constant - K19
45 FP Write PMK20 Module constant - K20
46 FP Write PMK21 Module constant - K21
47 FP Write PMK22 Module constant - K22
48 FP Write PMK23 Module constant - K23
49 FP Write PMK24 Module constant - K24
50 FP Write PMK25 Module constant - K25
51 FP Write PMK26 Module constant - K26
52 FP Write PMK27 Module constant - K27
53 FP Write PMK28 Module constant - K28
54 FP Write PMK29 Module constant - K29
55 FP Write PMK30 Module constant - K30
56 FP Write PMK31 Module constant - K31
