FS-8700-19_Metasys_N2 Driver Manual Page 33 of 51
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]
Appendix D.2. Metasys DC9100 Memory Map
Note: The DC9100 is not currently supported by the FieldServer MetasysN2 Driver.
The information below is for interest and future use only.
PAGE 0
Item
DEC Item
HEX
Signal Condition Read/Write
Johnson
Tag
Description
0 0 Byte Read MODL
Device model. Value always either 2 or
12
1 1 FP Read INP1 Analog input 1
2 2 FP Read INP2 Analog input 2
3 3 FP Read INP3 Analog input 3
4 4 FP Read INP4 Analog input 4
5 5 FP Read INP5 Analog input 5
6 6 FP Read INP6 Analog input 6
7 7 FP Read INP7 Analog input 7
8 8 FP Read INP8 Analog input 8
9 9 FP Read NCM1 Numeric calculation modul result
10 A FP Read NCM2 Numeric calculation modul result
11 B FP Read NCM3 Numeric calculation modul result
12 C FP Read NMC4 Numeric calculation modul result
13 D FP Write REC1 Remote constant 1
14 E FP Write REC2 Remote constant 2
15 F FP Write REC3 Remote constant 3
16 10 FP Write REC4 Remote constant 4
17 11 FP Write OUT1 Control output 1
18 12 FP Write OUT2 Control output 2
19 13 FP Write OUT3 Control output 3
20 14 FP Write OUT4 Control output 4
21 15 FP Write OUT5 Control output 5
22 16 FP Write OUT6 Control output 6
23 17 FP Write OUT7 Control output 7
24 18 FP Write OUT8 Control output 8
25 19 FP Write WSP1 Working setpoint 1
26 1A FP Write WSP2 Working setpoint 2
27 1B FP Write WSP3 Working setpoint 3
28 1C FP Write WSP4 Working setpoint 4
29 1D FP Write WSP5 Working setpoint 5
30 1E FP Write WSP6 Working setpoint 6
31 1F FP Write WSP7 Working setpoint 7
32 20 FP Write WSP8 Working setpoint 8
33 21 Word Read STW1 Status word 1
34 22 Word Read STW2 Status word 2
35 23 Word Read STW3 Status word 3
36 24 Word Read STW4 Status word 4
37 25 Word Read STW5 Status word 5
38 26 Word Read STW6 Status word 6
39 27 Word Read STW7 Status word 7
40 28 Word Read STW8 Status word 8
41 29 Word Write DOUT Logic output DDC control
42 2A Byte Write CHLD Hold mode control
43 2B Byte Write COMP Supervisory mode control
