FS-8700-19_Metasys_N2 Driver Manual Page 42 of 51
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: [email protected]
General dynamic Parameters
Relative Item Signal Condition Read/Write Johnson Tag Description
B(8) Supervisory System Active Refresh
38 Byte Read LSC Control & status
B(1) MNT Maintenance Started
B(2) Maintenance Stopped
B(3) RAS Reverse Action
B(4) Loop #1 Active
B(5) IAS Intrusion Alarm
B(6) AFM Anti freezing Mode Active
B(7) FOS Three speed Fan Override Real Status
B(8) Loop #3 Active
39 FP Write PM1K1 Constant K1 Module #1
40 Byte R/W PM1I@1 Input Connection I1@
41 Byte R/W PM1I@2 Input Connection I2@
42 Byte R/W PM1I@3 Input Connection I3@
43 Word R/W PM1TYP Options
44 FP R/W PM1K2 Constant K2
45 FP R/W PM1K3 Constant K3
46 FP R/W PM1K4 Constant K4
47 FP R/W PM1K5 Constant K5
48 FP R/W PM1K6 Constant K6
49 FP R/W PM1K7 Constant K7
50 FP R/W PM2K1 Constant K1 Module #2
51 Byte R/W PM2I@1 Input Connection I1@
52 Byte R/W PM2I@2 Input Connection I2@
53 Byte R/W PM2I@3 Input Connection I3@
54 FP R/W PM2TYP Options
55 FP R/W PM2K2 Constant K2
56 FP R/W PM2K3 Constant K3
57 FP R/W PM2K4 Constant K4
58 FP R/W PM2K5 Constant K5
59 FP R/W PM2K6 Constant K6
60 FP R/W PM2K7 Constant K7
61 FP R/W PM3K1 Constant K1 Module #3
62 Byte R/W PM3I@1 Input Connection I1@
63 Byte R/W PM3I@2 Input Connection I2@
64 Byte R/W PM3I@3 Input Connection I3@
65 FP R/W PM3TYP Options
66 FP R/W PM3K2 Constant K2
67 FP R/W PM3K3 Constant K3
68 FP R/W PM3K4 Constant K4
69 FP R/W PM3K5 Constant K5
70 FP R/W PM3K6 Constant K6
71 FP R/W PM3K7 Constant K7
72 FP R/W PM4K1 Constant K1 Module #4
73 Byte R/W PM4I@1 Input Connection I1@
74 Byte R/W PM4I@2 Input Connection I2@
75 Byte R/W PM4I@3 Input Connection I3@
76 FP R/W PM4TYP Options
77 FP R/W PM4K2 Constant K2
78 FP R/W PM4K3 Constant K3
79 FP R/W PM4K4 Constant K4
80 FP R/W PM4K5 Constant K5
81 FP R/W PM4K6 Constant K6
82 FP R/W PM4K7 Constant K7
83 FP R/W PM5K1 Constant K1 Module #5
84 Byte R/W PM5I@1 Input Connection I1@
85 Byte R/W PM5I@2 Input Connection I2@
