3 Update Procedures
In the case of MMB BX400S1 and BX900 S1: Up to ServerView Oper-
ations Manager V6.10, communication was processed using SNMP.
ssh login is evaluated as of Operations Manager V6.11.
4. The object-specific update job for the management blade is generated
by the Update Manager.
5. The Update Manager transfers the update images and the update job
(incl. update handler and update tool) to the TFTP server and starts the
update job (socket communication between the Update Manager and
the update agent on the TFTP server).
6. The update agent starts the update handler, and this starts the update
tool with the required parameters from the job control file supplied.
7. The update tool starts the dialog with the management blade and trans-
fers the required update parameters using SNMP or ssh commands.
8. The download of the images from the TFTP server and the update pro-
cedure are then controlled completely by the management blade (TFTP
communication).
9. The return values from the components involved are transferred in the
reverse order from the update tool via the update handler to the update
agent.
10. The update agent updates the job status information.
11. The Update Manager fetches the current status and error information
and presents it on the graphical user interface or, if you are using the
CLI, places it in result files.
The update procedure has then been completed.
