5 User Interface
Figure 19: Enter TFTP step
The table shows a subset of the servers selected on the tab. For the servers
displayed here, update will be done via the TFTP server.
Column Meaning
Server Name of the server
TFTP Address IP address of the TFTP server
Temporary Flash
Address Temporary IP address used for flashing the
management blade (MMBS2 only)
Change TFTP Address
Click this button to change the IP address of the TFTP server for the
selected server.
Change Flash Address
Click this button to change the temporary IP address used for flashing the
management blade (MMBS2 only).
Schedule Job step (Create Job Wizard)
Schedule Job is the last step in the wizard. Here you specify the time at
which the job is to be executed.
