RESTRICTED USE ONLY Fargo Electronics, Inc.
Persona C16 Card Printer Service Manual (Rev. 5.0) 59
Resolving the Image Placement problems
Symptom: Printing is cut off or is not centered on the card or a white border appears.
Step Procedure
1 Verify if the Image Position option within the Calibrate tab is set incorrectly.
a. Open the Printer Control Panel from the Computer.
• If using Windows 95/98/ME, right click on the C11_C16 Card Printer Icon
and select Properties.
• If using Windows NT 4.0, right click on the C11_C16 Card Printer and
select Document Defaults.
• If using Windows 2000/XP, right click on the C11_C16 Card Printer and
select Printing Preferences.
b. Click on the Calibrate tab.
c. Adjust
the Vertical and/or Horizontal Image Position settings based on
where the white border is on the card.
Continued on the next page
