Persona C16 Card Printer Service Manual (Rev. 5.0)
168
Replacing the Printhead Harness Assembly (830162-00) (continued)
Steps Procedure
15
Use the thumb and index fingers of both hands to carefully pry the Print Circuit
Board from the Power Circuit Board.
16
Open the Upper Imaging Assembly.
17
Remove the screws from the four corners of the top cover.
18
Close the Upper Imaging Assembly.
19
Lift the top cover from the Printer
20
Take the two screws (130990) from the Fan Guard (150312); lift the fan out of
the Printer.
21
Remove the two screws (130971) that secure the Shield Sensor (810303) to the
Sensor Mount Bracket (810221).
22
Take the Ribbon Sensor Assembly from the Printer.
23
Remove the screw (130972) that secures the Headlift Sensor Switch to the
Front Plate/Print Assembly Sideplate (830302).
24
Lift the Headlift Sensor Switch out of the Printer.
25
Cut the Tie Wrap (140013) that attaches the Head Harness Assembly to the
Back Plate/Print Assembly Sideplate (830303).
26 Disconnect
the
cable
connectors
27
Take the Printhead Harness Assembly from the Printer.
