App en dix
MMDS Commands
A–71 MMDS0508 Target Interface
500,000 Hz divided by an integer. Thus, 50000 is valid, but 49000 is not. (If you
specify 49000, the system rounds the value up the the next higher valid frequency:
50000.)
A.1.3.21 Description
The SC command sets the source for the time tag clock, which increments the trace
buffer time tag. If this command includes no parameter values, the command
interpreter opens the Bus Analyzer Configuration dialog box. You can use the Time
Tag Clock page to reach the Clock Specification dialog box, then set the clock sources
interactively.
Example:
SC PROGRAM 100
Sets the programmable clock, running at 100Hz, as the time clock source.
Example:
SC OSC8MHZ
Sets the 8 Mhz oscillator as the time tag clock source.
SP
A.1.3.22 Short Description
set analyzer search pattern.
A.1.3.23 Description
The SP command defines a search pattern for the bus analyzer trace buffer. The go to
pattern (GP) command starts the search for the pattern defined by the most recent SP
command. If the SP command includes no parameter values, the command interpreter
opens the Bus Analyzer Configuration dialog box. You can use the Pattern page to
define the pattern interactively.
A.1.3.24 Syntax
SP [!] [(
