MMDS Target Comp onent
4.6 Communication Configuration
4–27 MMDS0508 Target Interface
The MotoSIL driver automatically tries to find the MMDS target, behaving as text
above explains.
If MotoSIL does not detect a target, the MotoSIL item remains in the main menu bar as
shown in
Figure 4.4 :
Figure 4.4 Loading MotoSIL Target
But after successful target loading, the MMDS0508 menu replaces the Target or
MotoSIL menu in the main menu bar as show in
Figure 4.5 .
Figure 4.5 Loading MMDS Target
4.6 Communication Configuration
In most situations, the debugger uses its default values to set communication with the
MMDS automatically. In case of any problems, the dialog box show in
Figure 4.6
appears, so that you can correct settings.
NOTE Another way to open this dialog box is selecting MotoSIL >
Connect... from the menu bar. This method is appropriate if previous
connection attempts failed and MotoSIL still is in the main menu.
